GCP Terraform 架构

VPC
└── subnet (10.0.0.0/20, GKE nodes only)
    No Cloud SQL or Memorystore; chart pods handle both

GKE Cluster
├── langsmith namespace
│   ├── frontend, backend, platform-backend, queue, ace-backend, playground
│   ├── clickhouse (in-cluster)
│   ├── postgres   (in-cluster)
│   └── redis      (in-cluster)
├── cert-manager
├── keda
└── envoy-gateway-system

GCS Bucket (trace payloads, always external)

postgres_source   = "in-cluster"
redis_source      = "in-cluster"
clickhouse_source = "in-cluster"

VPC
├── subnet (10.0.0.0/20, GKE nodes, pods, services)
│   └── Secondary ranges: pods 10.4.0.0/14, services 10.8.0.0/20
└── Private service connection (VPC peering to Google managed network)
    ├── Cloud SQL PostgreSQL  (private IP, regional standby)
    └── Memorystore Redis     (private IP, STANDARD_HA tier)

GKE Cluster
├── langsmith namespace
│   ├── frontend, backend, platform-backend, queue, ace-backend, playground
│   └── clickhouse (in-cluster; use LangChain Managed for production scale)
├── cert-manager
├── keda
└── envoy-gateway-system

GCS Bucket (Workload Identity, no static keys)

GKE pod
  └── Kubernetes ServiceAccount (annotated with iam.gke.io/gcp-service-account)
        └── IAM binding: roles/iam.workloadIdentityUser
              └── GCP Service Account
                    └── roles/storage.objectAdmin on the GCS bucket

Internet (HTTPS :443)
  ↓
Envoy Gateway  (envoy-gateway-system, external LoadBalancer IP)
  TLS terminated: cert-manager + Let's Encrypt or existing certificate
  │
  ├── /                     → frontend:80
  ├── /api/*                → backend:1984
  └── /api/v1/deployments/* → host-backend:1985  (LangSmith Deployment add-on)

Internal traffic (private IPs, never leaving VPC):
  backend       → Cloud SQL:5432    via private IP
  backend       → Memorystore:6379  via private IP
  backend       → GCS               via Workload Identity (native GCS mode)
  host-backend  → K8s API           reads deployment pod status
  listener      → K8s API           reconciles Deployment CRDs
  operator      → K8s API           creates and manages deployment pods

terraform.tfvars → terraform apply → kubernetes_secret (postgres, redis)

terraform.tfvars → terraform apply ─┬─→ kubernetes_secret (postgres, redis)
                                    └─→ Secret Manager (durable copy, survives cluster recreation)

google_project_service (APIs enabled)
  └── module.networking
        ├── module.gke_cluster
        │     └── time_sleep.wait_for_cluster
        │           ├── module.cloudsql      (count = postgres_source == "external")
        │           ├── module.redis         (count = redis_source    == "external")
        │           ├── module.storage
        │           ├── module.iam           (count = enable_gcp_iam_module)
        │           ├── module.secrets       (count = enable_secret_manager_module)
        │           ├── module.dns           (count = enable_dns_module)
        │           ├── module.k8s_bootstrap
        │           └── module.ingress       (count = install_ingress)
        └── (private_service_connection when external services)

# Cluster connectivity
gcloud container clusters get-credentials <cluster-name> --region <region> --project <project-id>
kubectl cluster-info
kubectl get nodes -o wide

# All LangSmith pods
kubectl get pods -n langsmith

# Envoy Gateway
kubectl get pods -n envoy-gateway-system
kubectl get svc -n envoy-gateway-system

# cert-manager
kubectl get pods -n cert-manager
kubectl get certificate -n langsmith

# KEDA (LangSmith Deployment add-on)
kubectl get pods -n keda

# Cloud SQL connectivity test
kubectl run psql-test --rm -it --image=postgres:15 -n langsmith -- \
  psql "postgresql://langsmith:<password>@<cloud-sql-private-ip>:5432/langsmith" -c "SELECT version();"

# Memorystore connectivity test
kubectl run redis-test --rm -it --image=redis:7 -n langsmith -- \
  redis-cli -h <redis-private-ip> ping

# GCS connectivity test
kubectl run gcs-test --rm -it --image=google/cloud-sdk -n langsmith -- \
  gsutil ls gs://<bucket-name>
